Name：Anti interference magnetic ring

Model：ZCAT2035-0930

external diameter：20.0mm internal diameter：9.0mm height：35.0mm

Adaptive range:Various fever wires，USBLine Data line AVLine，Audio and video wires，Effective shieldingEMIinterfere，Isolate or filter the high-frequency noise pulse interference caused by the power connecting wire running into the equipment circuit，If it is used on the power line of audio and video appliances, it can further improve the quality of audio and video，No doubt it's the choice of audiophiles。For audio cable，Video cable, etc，It increases the purity of the sound system，Reduce the interference of signal line by power line noise.

Signal line application:Ferrite anti-interference core can also be used in signal line，To suppress the transmission of noise between components or equipment。But the impedance of the signal line is generally greater than that of the power line，So the interference suppression effect will be less obvious than that on the power line。

Magnetic ring selection:The shape and size of ferrite core affect the interference suppression effect，Generally, the larger the ferrite core is，The better the inhibition。At a certain volume，A long, thin core has a greater impedance than a short, thick core，More inhibition good。In case of bias current，Consider saturation，The larger the cross section of ferrite core，Less saturated，The greater the bias that can be tolerated。in addition，The smaller the inner diameter of ferrite core，The better the inhibition。 in short，The selection principle of ferrite core is：Under the condition that the use space allows，Choose as long as possible、Core as thick as possible and as small as inner hole。

Reminder

One、Rings are sold by size，Companymm(millimeter）

Two、Please measure the wire diameter before purchase，Don't just imagine buying，If you don't know, please consult customer service。

Three、According to the product description size of the page，LinepathThin lines，You can make more rounds on it，The effect is better.。
